LED 照明 - COB、エンジン、モジュール、ストリップ
| 写真: | メーカー部品番号 | 在庫状況 | 価格 | 数量 | データシート | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CXA2590-0000-000R0YW427GLED COB CXA2590 2700K WHT SMD CreeLED, Inc. |
2,762 | - |
RFQ |
データシート |
Tray | XLamp® CXA2590 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 5408lm (5225lm ~ 5590lm) | 1.2A | 85°C | 72V | 63 lm/W | 1.8A | 93 | 115° | - | 23.85mm L x 23.85mm W | 1.55mm | 19.00mm Dia |
|
|
CXA2590-0000-000R0YW427HLED COB CXA2590 2700K WHT SMD CreeLED, Inc. |
2,560 | - |
RFQ |
データシート |
Tray | XLamp® CXA2590 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Square | 5408lm (5225lm ~ 5590lm) | 1.2A | 85°C | 72V | 63 lm/W | 1.8A | 93 | 115° | - | 23.85mm L x 23.85mm W | 1.55mm | 19.00mm Dia |
|
|
CXA2590-0000-000R0YX227GLED COB CXA2590 2700K WHT SMD CreeLED, Inc. |
2,514 | - |
RFQ |
データシート |
Tray | XLamp® CXA2590 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 5800lm (5590lm ~ 6010lm) | 1.2A | 85°C | 72V | 67 lm/W | 1.8A | 93 | 115° | - | 23.85mm L x 23.85mm W | 1.55mm | 19.00mm Dia |
|
|
CXA2590-0000-000R0YX230GLED COB CXA2590 3000K WHT SMD CreeLED, Inc. |
2,891 | - |
RFQ |
データシート |
Tray | XLamp® CXA2590 | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 5800lm (5590lm ~ 6010lm) | 1.2A | 85°C | 72V | 67 lm/W | 1.8A | 93 | 115° | - | 23.85mm L x 23.85mm W | 1.55mm | 19.00mm Dia |
|
|
CXA2590-0000-000R0YX430GLED COB CXA2590 3000K WHT SMD CreeLED, Inc. |
2,913 | - |
RFQ |
データシート |
Tray | XLamp® CXA2590 | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 6220lm (6010lm ~ 6430lm) | 1.2A | 85°C | 72V | 72 lm/W | 1.8A | 93 | 115° | - | 23.85mm L x 23.85mm W | 1.55mm | 19.00mm Dia |
|
|
CXA2590-0000-000R0YX435GLED COB CXA2590 3500K WHT SMD CreeLED, Inc. |
3,891 | - |
RFQ |
データシート |
Tray | XLamp® CXA2590 | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 6220lm (6010lm ~ 6430lm) | 1.2A | 85°C | 72V | 72 lm/W | 1.8A | 93 | 115° | - | 23.85mm L x 23.85mm W | 1.55mm | 19.00mm Dia |
|
|
CXA2590-0000-000R0YY235GLED COB CXA2590 3500K WHT SMD CreeLED, Inc. |
2,714 | - |
RFQ |
データシート |
Tray | XLamp® CXA2590 | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 6670lm (6430lm ~ 6910lm) | 1.2A | 85°C | 72V | 77 lm/W | 1.8A | 93 | 115° | - | 23.85mm L x 23.85mm W | 1.55mm | 19.00mm Dia |
|
CXA3070-0000-000N00AB35GLED COB CXA3070 3500K WHT SMD CreeLED, Inc. |
3,899 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 8750lm (8500lm ~ 9000lm) | 1.9A | 85°C | 36V | 128 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N00Y427GLED COB CXA3070 2700K WHT SMD CreeLED, Inc. |
3,354 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 7150lm (6910lm ~ 7390lm) | 1.9A | 85°C | 36V | 105 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N00Z227GLED COB CXA3070 2700K WHT SMD CreeLED, Inc. |
3,071 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 7668lm (7390lm ~ 7945lm) | 1.9A | 85°C | 36V | 112 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N00Z230GLED COB CXA3070 3000K WHT SMD CreeLED, Inc. |
3,296 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 7668lm (7390lm ~ 7945lm) | 1.9A | 85°C | 36V | 112 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N00Z235GLED COB CXA3070 3500K WHT SMD CreeLED, Inc. |
3,264 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 7668lm (7390lm ~ 7945lm) | 1.9A | 85°C | 36V | 112 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N00Z427GLED COB CXA3070 2700K WHT SMD CreeLED, Inc. |
2,432 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 8223lm (7945lm ~ 8500lm) | 1.9A | 85°C | 36V | 120 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N00Z430GLED COB CXA3070 3000K WHT SMD CreeLED, Inc. |
2,370 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 8223lm (7945lm ~ 8500lm) | 1.9A | 85°C | 36V | 120 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N00Z435GLED COB CXA3070 3500K WHT SMD CreeLED, Inc. |
2,552 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 8223lm (7945lm ~ 8500lm) | 1.9A | 85°C | 36V | 120 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N0HAB40GLED COB CXA3070 4000K WHT SMD CreeLED, Inc. |
3,651 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 8750lm (8500lm ~ 9000lm) | 1.9A | 85°C | 36V | 128 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N0HAB50GLED COB CXA3070 5000K WHT SMD CreeLED, Inc. |
2,598 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 8750lm (8500lm ~ 9000lm) | 1.9A | 85°C | 36V | 128 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N0HAD40GLED COB CXA3070 4000K WHT SMD CreeLED, Inc. |
2,040 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 9250lm (9000lm ~ 9500lm) | 1.9A | 85°C | 36V | 135 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N0HAD50GLED COB CXA3070 5000K WHT SMD CreeLED, Inc. |
2,403 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 9250lm (9000lm ~ 9500lm) | 1.9A | 85°C | 36V | 135 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
|
|
CXA3070-0000-000N0HZ440GLED COB CXA3070 4000K WHT SMD CreeLED, Inc. |
3,894 | - |
RFQ |
データシート |
Tray | XLamp® CXA3070 | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 8223lm (7945lm ~ 8500lm) | 1.9A | 85°C | 36V | 120 lm/W | 2.8A | 80 | 115° | - | 27.35mm L x 27.35mm W | 1.70mm | 23.00mm Dia |
