オプトアイソレータ - ロジック出力
| 写真: | メーカー部品番号 | 在庫状況 | 価格 | 数量 | データシート | Packaging | Series | ProductStatus | NumberofChannels | Inputs-Side1/Side2 | Voltage-Isolation | CommonModeTransientImmunity(Min) | InputType | OutputType | Current-Output/Channel | DataRate | PropagationDelaytpLH/tpHL(Max) | Rise/FallTime(Typ) | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | Voltage-Supply | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HCPL-2601-000EOPTOISO 3.75KV OPEN COLL 8DIP Broadcom Limited |
309 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 3750Vrms | 10kV/µs | DC | Open Collector, Schottky Clamped | 50 mA | 10MBd | 100ns, 100ns | 24ns, 10ns | 1.5V | 20mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Through Hole |
|
HCPL-7723-300EOPTOISO 3.75KV PUSH PULL 8DIP GW Broadcom Limited |
3,834 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 3750Vrms | 10kV/µs | Logic | Push-Pull, Totem Pole | 10 mA | 50MBd | 22ns, 22ns | 8ns, 6ns | - | - | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
|
HCPL-7710OPTOISO 3.75KV PUSH PULL 8DIP Broadcom Limited |
3,057 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 3750Vrms | 10kV/µs | Logic | Push-Pull, Totem Pole | 10 mA | 12.5MBd | 40ns, 40ns | 13ns, 5ns | - | - | 4.5V ~ 5.5V | -40°C ~ 100°C | Through Hole |
|
HCPL-6651OPTOISO 1.5KV OPEN COLL 16FLATPK Broadcom Limited |
2,354 | - |
RFQ |
データシート |
Tube | - | Active | 4 | 4/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.5V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
|
HCPL-261N-000EOPTOISO 3.75KV OPEN COLL 8DIP Broadcom Limited |
558 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 3750Vrms | 1kV/µs | DC | Open Collector, Schottky Clamped | 50 mA | 10MBd | 100ns, 100ns | 42ns, 12ns | 1.3V | 10mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Through Hole |
|
|
HCPL-5201OPTOISO 1.5KV TRI-STATE 8DIP Broadcom Limited |
3,492 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 1500VDC | 1kV/µs | DC | Tri-State | 15 mA | 5MBd | 350ns, 350ns | 45ns, 10ns | 1.3V | 8mA | 4.5V ~ 20V | -55°C ~ 125°C | Through Hole |
|
ACPL-C61L-060EOPTOISO 5KV TRI-STATE 8SO Broadcom Limited |
3,654 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 5000Vrms | 20kV/µs | DC | Tri-State | 10 mA | 10MBd | 90ns, 90ns | 12ns, 12ns | 1.5V | 8mA | 2.7V ~ 5.5V | -40°C ~ 105°C | Surface Mount |
|
HCPL-1930OPTOISO 1.5KV 2CH OPEN COL 16DIP Broadcom Limited |
2,859 | - |
RFQ |
データシート |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10Mbps | 100ns, 100ns | 30ns, 24ns | - | 60mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
HCPL-6230OPTOISO 1.5KV PUSH PULL 20LCCC Broadcom Limited |
2,666 | - |
RFQ |
データシート |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Push-Pull, Totem Pole | 15 mA | 5MBd | 350ns, 350ns | 45ns, 10ns | 1.3V | 8mA | 4.5V ~ 20V | -55°C ~ 125°C | Surface Mount |
|
|
HCPL-2630OPTOISO 3.75KV 2CH OPEN COL 8DIP Broadcom Limited |
3,563 | - |
RFQ |
データシート |
Tube | - | Active | 2 | 2/0 | 3750Vrms | 5kV/µs | DC | Open Collector, Schottky Clamped | 50 mA | 10MBd | 100ns, 100ns | 24ns, 10ns | 1.5V | 15mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Through Hole |
|
ACNV4506-300EOPTOISO 7.5KV OPEN COLL 10DIP GW Broadcom Limited |
3,685 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 7500Vrms | 30kV/µs | DC | Open Collector, Schottky Clamped | 15 mA | - | 550ns, 400ns | - | 1.5V | 25mA | 4.5V ~ 30V | -40°C ~ 105°C | Surface Mount |
|
|
HCPL-0211OPTOISO 3.75KV PUSH PULL 8SO Broadcom Limited |
3,736 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 3750Vrms | 5kV/µs, 10kV/µs | DC | Push-Pull, Totem Pole | 25 mA | 5MBd | 300ns, 300ns | 30ns, 7ns | 1.5V | 10mA | 4.5V ~ 20V | -40°C ~ 85°C | Surface Mount |
|
|
HCPL-263A-000EOPTOISO 3.75KV 2CH OPEN COL 8DIP Broadcom Limited |
3,627 | - |
RFQ |
データシート |
Tube | - | Active | 2 | 2/0 | 3750Vrms | 1kV/µs | DC | Open Collector, Schottky Clamped | 50 mA | 10MBd | 100ns, 100ns | 42ns, 12ns | 1.3V | 10mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Through Hole |
|
ACPL-P456-000EOPTOISO 3.75KV OPN COLLECTOR 6SO Broadcom Limited |
3,749 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 3750Vrms | 15kV/µs | DC | Open Collector, Schottky Clamped | 15 mA | - | 550ns, 400ns | - | 1.5V | 25mA | 4.5V ~ 30V | -40°C ~ 100°C | Surface Mount |
|
ACPL-M75L-000EOPTOISO 3.75KV PUSH PULL 5SO Broadcom Limited |
2,591 | - |
RFQ |
データシート |
Tube | - | Active | 1 | 1/0 | 3750Vrms | 10kV/µs | DC | Push-Pull, Totem Pole | 10 mA | 15MBd | 55ns, 55ns | 3.5ns, 3.5ns | 1.5V | 10mA | 3V ~ 3.6V, 4.5V ~ 5.5V | -40°C ~ 105°C | Surface Mount |
|
ACPL-K73L-560EOPTOISO 5KV 2CH PUSH PULL 8SSO Broadcom Limited |
2,916 | - |
RFQ |
データシート |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 | 2/0 | 5000Vrms | 10kV/µs | DC | Push-Pull, Totem Pole | 10 mA | 15MBd | 55ns, 55ns | 3.5ns, 3.5ns | 1.5V | 10mA | 3V ~ 3.6V, 4.5V ~ 5.5V | -40°C ~ 105°C | Surface Mount |
|
|
HCPL-0601-560EOPTOISO 3.75KV OPN COLLECTOR 8SO Broadcom Limited |
2,842 | - |
RFQ |
データシート |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 3750Vrms | 10kV/µs | DC | Open Collector, Schottky Clamped | 50 mA | 10MBd | 100ns, 100ns | 24ns, 10ns | 1.5V | 20mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
|
HCPL-4506-500EOPTOISO 3.75KV OPEN COLL 8DIP GW Broadcom Limited |
3,755 | - |
RFQ |
データシート |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 3750Vrms | 15kV/µs | DC | Open Collector, Schottky Clamped | 15 mA | - | 550ns, 400ns | - | 1.5V | 25mA | 4.5V ~ 30V | -40°C ~ 100°C | Surface Mount |
|
|
ACPL-061L-500EOPTOISO 3.75KV TRI-STATE 8SO Broadcom Limited |
2,431 | - |
RFQ |
データシート |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 3750Vrms | 20kV/µs | DC | Tri-State | 10 mA | 10MBd | 80ns, 80ns | 12ns, 12ns | 1.3V | 8mA | 2.7V ~ 5.5V | -40°C ~ 105°C | Surface Mount |
|
|
HCPL-0201-500EOPTOISO 3.75KV PUSH PULL 8SO Broadcom Limited |
3,736 | - |
RFQ |
データシート |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 3750Vrms | 1kV/µs | DC | Push-Pull, Totem Pole | 25 mA | 5MBd | 300ns, 300ns | 30ns, 7ns | 1.5V | 10mA | 4.5V ~ 20V | -40°C ~ 85°C | Surface Mount |
